FS
Fixed skylights, pitched roof
Daylight for tiled or tin roofs where you don't need fresh air.
- 15° to 90° pitch
- BAL 401
- 10 year warranty2
- CodeMark certified
From $497.11 incl. GSTSee FS sizes & prices
Dark hallway, kitchen or ensuite? Compare every fixed VELUX skylight size and price in one place, for pitched tiled or tin roofs and flat roofs, then buy online. Prices are product only and shown upfront. As an authorised VELUX dealer, we supply the full range from our showroom in Heidelberg Heights. Collect, or we deliver across Melbourne & VIC.
Not sure which size or model suits your roof? Call 03 9455 0544 or send us your room size and a photo, and we'll suggest one.
Diamond Skylights is an authorised VELUX dealer with a showroom in Heidelberg Heights, Melbourne. We sell VELUX fixed skylights online from $337.65 for a flat roof FCM and $497.11 for a pitched roof FS, and opening skylights (VS, VSS, VSE, VCM and VCS) from $1,132.30, all product only and incl. GST. We deliver across Melbourne and VIC, or you can collect from our showroom.
Fantastic service, prompt, friendly and by far the best price I found for my purchase. Will definitely be using Diamond Skylights again for any of my building projects. Highly recommend.
Start with your roof (pitched or flat), then decide if you want fresh air as well as light.
FS
Daylight for tiled or tin roofs where you don't need fresh air.
FCM
For flat and low pitch roofs, and a neat upgrade for old plastic domes.
VS · VSS · VSE
Let steam and heat out of bathrooms and kitchens. Manual, solar or electric.
VCM · VCS
Fresh air for flat roofs, with a hand winder or a solar keypad.
GGL · GPL
For attics and loft rooms where the window is within reach.
Tell us your roof type and the room, and we'll point you to the right VELUX.
Figures from VELUX Australia product sheets (2022 and 2024) and the VELUX 2025 brochure. From prices are product only. VELUX and the VELUX logo are registered trademarks of VKR Holding A/S.
Prices and sizes last checked . Sizes from VELUX Australia’s official size charts.
For pitched tiled or tin roofs from 15° to 90°. The FS is fixed (it doesn't open) and comes double glazed as standard. The letter in the size code sets the width (C = 550 mm, M = 780 mm, S = 1140 mm) and the number sets the height. C sizes are made to fit between rafters at 600 mm centres.
| Size code | Overall frame size (W × H) | From price (product only) | Internal glass size | Daylight area (approx.) | Suited rooms | Buy |
|---|---|---|---|---|---|---|
| FS C01 | 550 × 700 mm | $497.11 product only | 462 × 611 mm | 0.28 m² | Toilet, walk-in robe, small hallway | |
| FS C04 | 550 × 980 mm | $574.61 product only | 462 × 891 mm | 0.41 m² | Ensuite, hallway, stairwell | |
| FS C06 | 550 × 1180 mm | $659.25 product only | 462 × 1091 mm | 0.50 m² | Bathroom, laundry, hallway | |
| FS C08 | 550 × 1400 mm | $736.76 product only | 462 × 1311 mm | 0.61 m² | Bathroom, laundry, stairwell | |
| FS C12 | 550 × 1800 mm | $1,042.33 product only | 462 × 1713 mm | 0.79 m² | Long hallway, stairwell | |
| FS M02 | 780 × 780 mm | $677.96 product only | 692 × 691 mm | 0.48 m² | Bathroom, laundry, ensuite | |
| FS M04 | 780 × 980 mm | $715.38 product only | 692 × 891 mm | 0.62 m² | Bathroom, laundry, kitchen | |
| FS M06 | 780 × 1180 mm | $809.81 product only | 692 × 1091 mm | 0.75 m² | Kitchen, bedroom, family room | |
| FS M08 | 780 × 1400 mm | $906.03 product only | 692 × 1311 mm | 0.91 m² | Kitchen, living room, bedroom | |
| FS S01 | 1140 × 700 mm | $788.43 product only | 1052 × 611 mm | 0.64 m² | Living room, kitchen (wide, low opening) | |
| FS S06 | 1140 × 1180 mm | $940.77 product only | 1052 × 1091 mm | 1.15 m² | Living room, open-plan kitchen/dining |
All prices are product only (AUD, incl. GST, as shown in our store) for the skylight unit. They do not include flashing kits, blinds, delivery or installation. Prices and stock are pulled live from our store and shown on each product page at checkout.
FS skylights need a VELUX flashing kit to suit your roof, sold separately: EDW for tiles and low-profile metal such as corrugated, EDL for slate or shingle. EDW isn't suitable for wide-span metal such as Klip-Lok or Trimdek, so ask us about those roofs. Shop all pitched-roof skylights · Shop all fixed skylights
For flat and low-pitch roofs from 0° to 60°, and a common way to replace an old plastic dome: VELUX makes 11 FCM sizes to suit common dome sizes (a collar adaptor may be needed). The FCM sits on an upstand (curb) built on the roof, and VELUX recommends a slight 3° to 5° pitch so water runs off the glass. The four-digit size code is shared across the flat-roof range, so an FCM, VCM and VCS with the same code fit the same opening.
| Size code | Overall frame size (W × H) | From price (product only) | Internal glass size | Daylight area (approx.) | Suited rooms | Buy |
|---|---|---|---|---|---|---|
| FCM 1430 | 460 × 870 mm | $337.65 product only | 368 × 775 mm | 0.29 m² | Toilet, pantry, walk-in robe (narrow) | |
| FCM 2222 | 665 × 665 mm | $366.16 product only | 572 × 572 mm | 0.33 m² | Toilet, ensuite, small hallway | |
| FCM 2230 | 665 × 870 mm | $398.22 product only | 572 × 775 mm | 0.44 m² | Ensuite, bathroom, hallway | |
| FCM 2234 | 665 × 970 mm | $421.39 product only | 572 × 876 mm | 0.50 m² | Bathroom, laundry, hallway | |
| FCM 2246 | 665 × 1275 mm | $478.40 product only | 572 × 1181 mm | 0.68 m² | Bathroom, kitchen, hallway | |
| FCM 2270 | 665 × 1885 mm | $862.37 product only | 572 × 1792 mm | 1.02 m² | Long hallway, corridor | |
| FCM 3030 | 870 × 870 mm | $462.37 product only | 775 × 775 mm | 0.60 m² | Bathroom, laundry, kitchen | |
| FCM 3046 | 870 × 1275 mm | $587.09 product only | 775 × 1181 mm | 0.92 m² | Kitchen, bedroom, living room | |
| FCM 3055 | 870 × 1505 mm | $716.27 product only | 775 × 1410 mm | 1.09 m² | Kitchen, living room, bedroom | |
| FCM 3072 | 870 × 1935 mm | $1,818.28 product only | 775 × 1842 mm | 1.43 m² | Living room, open-plan area | |
| FCM 3434 | 970 × 970 mm | $526.51 product only | 876 × 876 mm | 0.77 m² | Bathroom, kitchen; replaces old 800 to 900 mm square domes | |
| FCM 3446 | 970 × 1275 mm | $620.06 product only | 876 × 1181 mm | 1.03 m² | Kitchen, living room | |
| FCM 4646 | 1275 × 1275 mm | $651.24 product only | 1181 × 1181 mm | 1.39 m² | Living room, open-plan area | |
| FCM 4672 | 1275 × 1935 mm | $2,023.19 product only | 1181 × 1842 mm | 2.17 m² | Large living or open-plan area |
All prices are product only (AUD, incl. GST, as shown in our store) for the skylight unit. They do not include flashing kits, blinds, delivery or installation. Prices and stock are pulled live from our store and shown on each product page at checkout.
FCM skylights mount on a site-built upstand and don't include flashing: VELUX specifies a custom-made curb flashing to suit your roof. Blinds and blind trays are sold separately. Shop all flat-roof skylights · Shop VELUX blinds
Steamy bathroom or hot kitchen? An opening VELUX lets steam and heat out as well as light in. Each range comes in standard sizes. Compare sizes and prices on each range page.
For a steamy bathroom, laundry or kitchen you can reach. VS suits pitched roofs and VCM suits flat roofs. Both open with a hand winder (or a rod for high ceilings, sold separately) and come with a flyscreen.
From $1,132.30 (VS, product only) · from $1,195.56 (VCM)
Shop manual opening skylightsFor a high ceiling or hard-to-reach room with no power nearby. Solar models open and close with a wall keypad, run on a solar panel that charges a hidden battery (no electrician needed), and close themselves when the rain sensor detects rain. Flyscreen included.
From $2,297.58 (VSS, pitched) · from $2,236.11 (VCS, flat)
Shop solar skylightsFor a pitched roof with a power point in the roof cavity. VSE skylights plug into a standard power point (no hard wiring), open with a wall keypad, and the included rain sensor closes them when it starts to rain.
From $2,130.99 (product only)
Shop electric skylightsFor attics, loft rooms and upstairs rooms where the window is within reach. GGL centre-pivot windows open from a bar at the top and rotate so you can clean the outside from indoors. GPL dual-action windows also open from a bottom handle.
From $750.12 (GGL) · from $893.55 (GPL)
Shop roof windowsOpening-range prices are product only. Flashing kits, blinds, controls, delivery and installation are extra.
As a rough guide, aim for skylight glass area of about 5 to 10% of the room's floor area. Go towards 5% if the room already has good windows, and towards 10% if it's very dark or south-facing. For example, a 10 m² bathroom suits about 0.5 to 1.0 m² of glass, which is roughly an FCM 3030 (0.60 m² of glass) or an FS M06 (0.75 m² of glass). If the room gets strong afternoon sun, add a VELUX blind to control heat and glare.
For pitched roofs, the FS width also has to suit your rafter spacing. C sizes (550 mm wide) suit rafters at 600 mm centres without cutting a rafter. Wider M and S sizes may need framing work, so check with your builder. Still unsure? Send us your room size and a photo of your roof and we'll suggest a size.
Example: an FCM 3046 is 870 × 1275 mm overall, with 775 × 1181 mm of glass. That's about 0.92 m² of daylight.
VELUX fixed skylights start from $337.65 for a flat-roof FCM and $497.11 for a pitched-roof FS, product only and incl. GST. Opening models start from $1,132.30 (manual) and solar models from $2,236.11. Flashing kits, blinds, delivery and installation are extra. The price tables above show every fixed size.
Because the skylight is only part of the job. Depending on your roof and ceiling, installation can include cutting and framing the roof opening, fitting the flashing, building and plastering the light shaft, painting, and power for electric models. That’s why the prices on this page are product only and installation is quoted separately.
How it’s flashed and installed matters most, so don’t cut corners there. Each FS uses a VELUX flashing kit made for your roof type: EDW for tiles and low-profile metal, EDL for slate or shingle. FCM flat-roof skylights sit on a curb with custom-made flashing, and VELUX recommends a slight 3° to 5° pitch so water runs off. The VELUX warranty on the skylight is 10 years (3 years on blinds, electric and solar parts). Not sure about your roof? Ask us before you buy.
VELUX double glazing is standard and blocks heat: VELUX rates it at about 75% of radiant heat blocked on the FS and about 70% on the FCM. For a room that gets strong sun, add a VELUX blind (in VELUX testing, its honeycomb blinds cut heat by about 70%), or choose an opening model so hot air can escape.
Use the sizing guide above as a starting point, then check the overall frame size fits your rafters or upstand. If you’re still unsure, call 03 9455 0544 or send us your room size and a photo of your roof, and we’ll suggest a size.
A fixed skylight is sealed and doesn’t open. It’s the most affordable way to add daylight. An opening skylight (manual, solar or electric) lets fresh air, steam and heat out, which suits bathrooms, kitchens and laundries. Solar and electric models close themselves when it rains.
Usually, yes. The VELUX FCM is made for flat and low-pitch roofs from 0° to 60°, and VELUX makes 11 FCM sizes to suit common acrylic dome sizes (a collar adaptor may be needed). For fresh air as well, the manual VCM and solar VCS come in the same size codes.
Both work. Our own installers fit VELUX skylights across Melbourne, so ask us for a free quote. Or buy online and have your builder or roofer fit it with the matching flashing kit. Installation must meet building and roofing requirements, so use a qualified installer.
VELUX glass has a NEAT coating on the outer pane. Sunlight helps it break down dirt and rain rinses it away, so it needs cleaning less often. GGL and GPL roof windows also rotate so you can clean the outside from indoors.
Overall size is the outside of the frame, which is what has to fit your roof. Glass size is the clear area you see from inside, which is what lets light in. Glass size is always smaller.
VELUX skylights come in standard sizes, each with a size code. Pitched-roof FS skylights run from FS C01 (550 × 700 mm) to FS S06 (1140 × 1180 mm), and flat-roof FCM skylights from FCM 1430 (460 × 870 mm) to FCM 4672 (1275 × 1935 mm). Every fixed size is in the tables above.
Yes, we deliver to Melbourne and across Victoria (VIC only), or you can collect from our Heidelberg Heights showroom. Delivery is calculated at checkout.
Buy online now. Collect from Heidelberg Heights, or we deliver across Melbourne & VIC (calculated at checkout).
Not sure which size? Call 03 9455 0544 or send us a photo of your roof.
